Energy Storage Connector Series 1

High voltage energy storage connector 60A-400A IP67 Plastic 6mm-14mm Contact Plug HV connector The SS1 series products are connectors for energy storage systems, which are a type of energy storage connector developed by our company specifically for the energy storage industry. They mainly include three products: 60A~120A, 120A~200A, and 250A~400A. The socket of this series of products is individually sealed with IP67 (optional), and after the head seat is inserted, it can meet IP67 (optional). It has functions such as key position and positive and negative pole color double error prevention, 360 ° arbitrary angle insertion, etc., making it convenient and fast to achieve blind insertion. This product has been granted a patent for a 360 ° rotatable plug-in energy storage connector.

Send Inquiry

Appendix

Product Description

Lithium Battery Terminal HV Connector Energy Storage System Connector

High voltage energy storage connector 60A-400A IP67 Plastic 6mm-14mm Contact Plug HV connector

The SS1 series products are connectors for energy storage systems, which are a type of energy storage connector developed by our company specifically for the energy storage industry. They mainly include three products: 60A~120A, 120A~200A, and 250A~400A. The socket of this series of products is individually sealed with IP67 (optional), and after the head seat is inserted, it can meet IP67 (optional). It has functions such as key position and positive and negative pole color double error prevention, 360 ° arbitrary angle insertion, etc., making it convenient and fast to achieve blind insertion. This product has been granted a patent for a 360 ° rotatable plug-in energy storage connector.
